MSI PRO H610M-B D4 Hovedkort

LGA 1700, mATX, DDR4 3200mhz(max), PCIe 4.0 x16, M.2

Varenummer: 1206429 / Produktnr.: PRO H610M-B DDR4

Flere bilder av MSI PRO H610M-B D4 Hovedkort

1 106,- Eks. mva.
+ frakt fra 86,-
fra 37,- /mnd.
Leasing velges i kassen
39 stk. på lager. (1-2 dager leveringstid)

MSI PRO H610M-B D4

PRO Series

PRO series helps users work smarter by delivering an efficient and productive experience. Featuring stable functionality and high-quality assembly, PRO series motherboards provide not only optimized professional workflows but also less troubleshooting and longevity.

USER FRIENDLY DESIGN

MSI motherboards feature tons of convenient and smart design for DIY users, countless system tuning and troubleshooting tools are at your disposal to push your system to new heights and satisfy even the most demanding tweaker. Makes it so easy to install your own motherboard without any issue.

COOLING

FROZR AI COOLING

Detecting CPU & GPU temperatures and automatically adjusting fan duty of system fans to a proper value by adopting MSI AI ENGINE.

FULLY CONTROLLABLE IN BIOS AND SOFTWARE

MSI motherboards let you manage speeds and temperatures for all your system and CPU fans. Total Fan Control allows you check your primary system characteristics in a simplified graphical interface. You can also set up to 4 temperature targets for CPU and motherboard, which will adjust the fan speeds automatically.

DESIGN

EZ DEBUG LED

Ran into trouble? Onboard LEDs for key components will indicate the source of the problem so you know exactly where to look to get it up and running again.

COMPATABILITY

  • 12th processors support
  • Extreme stability & compatability testing for memory.
  • Windows 11 Certified

RELIABLE COMPONENTS

STEEL ARMOR

FORTIFY YOUR SYSTEM WITH PCI-E STEEL ARMOR. PCI Express Steel Armor slots are secured to the motherboard with extra solder points and support the weight of heavy graphics cards. When every advantage in games counts, Steel Armor shields the point of contact from electromagnetic interference.

DOUBLE ESD PROTECTION

Double ESD protection doubles up the grounding layer around the mounting holes, preventing static discharge surges from damaging the motherboard.

CONNECTIVITY

The most important thing of DIY is expandability. MSI PRO series motherboards feature plenty possibility for prosumers’ need. Stable LAN, faster storage and USB transfer speed and other expandable connectors are ready to enlarge your flexibility.

LAN

LOW LATENCY GAMING LAN POWERED BY INTEL®

Stay connected with Intel® LAN, optimized for stable internet throughput ideal for championship level online plays.

OPTIMIZE NETWORK FOR LOWER LATENCY!

MSI LAN Manager automatically classifies and prioritizes the latency-sensitive applications, giving you the best online experience with low latency.

MSI LAN MANAGER
Allows you to change applications' traffic priority
Allows you to customize bandwidth for each application

STORAGE

FAST AND FUTURE-READY STORAGE

MSI PRO series motherboards support all the latest storage standards, which allows users to connect any ultra-fast storage device. Higher efficiency makes your work easier.

USB

Transfer lots of data, music and movies over USB easier. USB 3.2 Gen 1 ports are ready in both front and rear IO, provides wide variety of options to connect your USB 3.2 Gen 1 devices.

EXPERIENCE MORE

MSI PRO series motherboards are designed to satisfy any professional workflow. Elevate your listening pleasure and enjoy extreme sound quality. Moreover, with years of experience in creating performance enhancing tools that are easy to use, only the highest quality applications are at your disposal. The extensive features let you fine-tune your system to deliver reliable maximum performance.

PERFORMANCE

LIGHTNING GEN 4 PCI-E

MSI lightning Gen 4 PCI-E is the latest and the fastest PCI-E data transfer solution with 64GB/s of transfer bandwidth that has doubled compared to its previous generation. PCIe 4.0 maintains both backward and forward compatibility with older and newer specifications. Optimized by steel armor design, your motherboards can support the weight of heavy graphics cards.

MEMORY BOOST

EXTREME STABILITY & COMPATIBILITY TESTING

MSI conducts thorough memory testing with the most popular memory brands under extreme conditions to ensure your system runs stable no matter what. Our memory partners include brands like Corsair, Crucial, Kingston, G.Skill and many more to optimize memory modules and configurations.

CORE BOOST

Core Boost technology combines MSI's premium layout and optimized power design which allows for faster and undistorted current delivery to the CPU at pin-point precision. Not only supporting multi-core CPU, also creating the perfect conditions for your CPU overclocking.

AUDIO

DEDICATED HIGH DEFINITION AUDIO PROCESSOR

Make sure you enjoy the purest sound quality in both stereo and surround sound.

HIGH QUALITY AUDIO CAPACITORS

A high fidelity sound experience with exceptional acoustics and realism for studio level headphones is ensured.

HD AUDIO CONNECTORS

Keep you sound perfect by transmit your aduio with pure digital signal.

ISOLATED AUDIO SIGNAL

ISOLATED AUDIO DESIGN

Like a dedicated sound card, audio components and circuits have been laid on a reserved motherboard section and electrically isolated.

SEPARATED AUDIO LAYERS FOR CLEAN LEFT & RIGHT CHANNELS

Using separated layers in the PCB ensures equally pristine sound quality for both left and right audio channels.

DE-POP PROTECTION

Audio Boost protects your ears by eliminating those annoying loud popping sounds when you plug/unplug devices or turn your PC on/off.

BIOS & SOFTWARE

MSI brand new MSI Center unifies a suite of MSI software utilities into a single centralized application. Take control of advanced motherboards features and unleash endless possibilities.

True Color
Optimized monitor’s brightness and color in several modes for different situation, you can also customize by yourself.

Live Update
Never miss out on important updates. MSI Live Update automatically downloads and installs the latest drivers, BIOS and software so you can focus on your work.

User Scenario
One click for setting your computer, even customize own profile as your preference.

Hardware Monitoring
Get immediate access to your critical hardware information in real-time.

Fan Center
Assume complete control of your fans with Fan Center. Set up to four CPU temperature targets and the motherboard will adjust fan speeds automatically.

Product Registration
Register your MSI product to enjoy a host of benefits!

CLICK BIOS 5

Get more from a loaded BIOS designed for ease of use. Fine-tune the motherboard for gaming performance, efficiency, or overclocking world records!

CREATOR GENIE

Quickly overclock your CPU with a single button for more performance.

XMP

Choose from a preset XMP profile and automatically overclock compatible DDR memory.

M-FLASH

Conveniently flash or upgrade the BIOS in a few minutes from the CMOS Setup Utility.

HARDWARE MONITOR

Get immediate access to your critical hardware information in real-time including temperature, memory capacity, clock speed, and voltage.

MEMORY TRY IT

Get extreme speed out of your system memory and get more performance.

SEARCH & FAVORITES

A permanent search & favorite option in the top right corner moves you through the BIOS menus quickly.

RESIZABLE BAR (RE-SIZE BAR)

Resizable BAR (Re-Size BAR) is an advanced PCI Express feature that enables the CPU to access the entire GPU frame buffer at once and improve performance.

*Function may differ due to version change. Please update the latest VBIOS/BIOS/Driver through MSI official website or consult service center.

PRO H610M-B DDR4

  • Supports 12th Gen Intel® Core™, Pentium® Gold and Celeron® processors for LGA 1700 socket
  • Supports DDR4 Memory, up to 3200(MAX) MHz
  • Core Boost : With premium layout and digital power design to support more cores and provide better performance
  • Memory Boost: Advanced technology to deliver pure data signals for the best performance, stability and compatibility
  • Lightning Fast Experience: PCIe 4.0
  • Audio Boost: Reward your ears with studio grade sound quality
  • Steel Armor: Protecting VGA cards against bending and EMI for better performance, stability and strength.
Generelt
Garanti (måneder) 36
Produkttype Hovedkort - mikro ATX
Brikkesett type Intel H610
Prosessorsokkel LGA1700-sokkel
Maks antall prosessorer 1
Kompatible prosessorer (støtter 12th Generation Intel Core / Pentium / Celeron)
EAN 4719072924980
Støttet RAM
Maks størrelse 128 GB
Teknologi DDR4
Bussklokke 2133 MHz, 2666 MHz, 3200 MHz
Støttet RAM-integritetskontroll Ikke-ECC
Registrert eller bufret Ikke-bufret
Egenskaper Dobbeltkanalsminnearkitektur
Lyd
Type HD-lyd (8-kanalers)
Audio Codec Realtek ALC892/ALC897
Tilpassede standarder High Definition Audio
LAN
Nettverkskontroller Intel I219V
Nettverksgrensesnitt Gigabit Ethernet
Ekspansjon / Tilkoplinger
Utvidelsesspor 1 x CPU
4 x 288-pins DIMM
1 x PCIe 4.0 x16
1 x M.2 socket (for trådløs modul)
1 x PCIe 3.0 x1
Lagergrensesnitt SATA-600 -kontakter: 4 x 7-pin seriell ATA
SATA-600 / PCIe 3.0 -kontakter: 1 x M.2
RAID-funksjoner Intel Smart Response Technology
Grensesnitt 1 x HDMI
1 x VGA
1 x LAN (Gigabit Ethernet)
2 x USB 3.2 Gen 1
4 x USB 2.0
1 x lydutlinje - minijakk
1 x mikrofon - minijakk
1 x lydinnlinje - minijakk
1 x PS/2-tastatur / -mus
Interne overflater 2 x USB 2.0 - header
2 x USB 3.2 Gen 1 - header
1 x lyd - header
Strømkontakter 24-pin hovedstrømforsyningskontakt, 8-pin ATX12V-kontakt
Egenskaper
BIOS-egenskaper MSI ClickBIOS 5
Maskinvarefunksjoner MSI Audio Boost, anti-pop-funksjon, Debug LED, MSI Steel Armor, Double ESD Protection, MSI Core Boost
Diverse
Tilleggsutstyr inkludert I/O-bakplate, merkeskilt, M.2-klips
Medfølgende kabler 2 x Seriell ATA-kabel
Bredde 24.4 cm
Dybde 21.1 cm
